Technical Specification
01. Wheel Size : 250 X 225 X 50
02. Wheel Dia : 250mm
03. Tread Width : 50 mm
04. Hub Width : 54mm
05. Shaft Dia Size : 40mm
06. No of Bearing : NA
07. Key Way Size : 12 X 6, Optional As Per Industrial Standard
08. Load Capacity : 2000 Kg / Per Wheel
09. Insert Material : Cast Iron (CI)
10. Coatin Material : Polyurethane (PU)
11. Hardness : 95, Shore A
12. Temperature : - 10 C to + 60 C
13. Ideal Surface : Tiles, Cement and Resin
14. Application : Overhead Crane, Electroplating Plant, Automation Material Transfer Line
15. Color : Natrual / Yellow, Black / Yellow, Natrual / Red, Black / Red or Customized Color
